Description
X-431 PAD V
Advanced Diagnostic Scanner
The X-431 PAD V LINK is a high-end professional diagnostic tool with a optional charging base newly developed on the basis of Android 7.1 open system. It comes with ADAS calibration functions, 39 service functions, TPMS services and other extended modules functions. The IP65 case is waterproof and dustproof to best protect the scan tool to use longer. All these unique features will offer you a luxury experience of vehicle diagnosis.
- We are a seller of OFFICIAL LAUNCH Diagnostic tooling
- FREE WORLD WIDE SHIPPING
- Global Version WITHOUT IP Restrictions
- 3 years free software updates
- 1.2 meter drop tested
- Topology mapping lets you visually check the DTCs and all systems communication status.
- Enables you to diagnose light, medium & heavy duty (optional software package) vehicles with the Smart box 3.0.
- Supports X-431 Fix database to fix the problems fast.
- Full system vehicle coverage for U.S., Asian, European and Australasian markets over 110 manufacturers, which is continually updated.
- Real-time voltage display is supported, which helps you monitor the voltage condition of the vehicle during the diagnosis.
- Supports automotive communication protocols CAN/CANFD/DoIP and automotive communication standards J2534/D-PDU/RP1210.
- Auto-detects the communication protocols of the vehicle to check if there is any OBDII port pins damaged or not.
- Intelligent diagnostic enables automatic VIN identity to automatically access systems quickly.
- Intelligent and local diagnostic, which include full diagnostic functions, such as read/clear DTC, live data streaming, bi-directional control, coding, programming, etc.
- Guided functions for Volkswagen and Audi.
- Optional ADAS calibration function increases more revenue.
- Advanced coding and programming function.
- An extended solution to support TPMS service.
- The software is available to purchase separately on the MALL at any time.
- Built-in repair information and training videos help to track and fix issues fast.
Launch X431 PAD V Vehicle Coverage:
Passenger Vehicles:
1. Australian: AUST Holden, AUST Ford
2. Asian: Toyota/ Lexus, Honda/ Acura, Mazda, Subaru, Nissan/ Infiniti, Mitsubishi, Hyundai, Isuzu, Daihatsu, KIA, Daewoo, Suzuki, Proton, Tata, Mahindra, Ssangyong, Perodua, Maruti
3. European: Audi, Mercedes/ Maybach, BMW/ MINI/ Rolls Royce, VW/ Bentley/ Bugatti, Opel/ Vauxhall, Peugeot, Citroen, Volvo, Sprinter, Renault/ Dacia, Fiat/ Romeo/ Abarth/ Lancia, Rover, Landrover, Saab, Seat, Skoda, Smart, Maserati, Ferrari, Arston Martin, Porsche, Jaguar
4. USA: USA Ford/ Lincoln, GM/ Buick/ Cadillac/ Chevrolet, Chrysler/ Dodge/ Jeep
5. Chinese: Changcheng (Great Wall), Geely, Qirui_TY(Cherry), Futian, Changan, Changhe, Haifei ….etc.
6. Special: Immobilizer/ Key, Injector, Reset Brake Bleed, Reset TPMS, Electronic Throttle Relearn, Reset DPF, Reset SAS, Reset Oil, Reset Brake, Reset BMS
7. Others: EOBD, Demo
Heavy Duty Vehicles (Optional, at an extra cost):
Nissan (Diesel)
Mitsubishi (Diesel)
USA Ford Diesel, Kenworth
Astra, Benz Heavy Duty, Bosch Diesel, China Heavy Duty, Cummins Heavy Duty, DAF, Delphi Diesel
Denso Diesel, FAW Liberation, Foton Auman, FUSO, Hino, Hyundai Heavy Duty, Isuzu Heavy Duty
Iveco Heavy Duty, JAC Heavy Duty, Mack , MAN , OBD Heavy Duty, Scania, Shangchai Diesel, Volvo Heavy Duty
WP Diesel, Airbus, Allison Transmission Box, Ashok Rejlander, Bendix ABS, Caterpillar Heavy Duty
Chai Heavy Vehicle, Chaoyang Diesel, Construction Machinery, CREDO Heavy Vechicle, Detroit Engine
Dongfeng Commercial Vehicle, Dongfeng Yufeng, Doosan Engine, Freightliner Heavy Duty Truck
Full Diesel Diagnosis Software, Haldex ABS Heavy Duty, HD_ABS System, HD_GoldenDragon, HD_International
HD_Kinglong, HD_Maxxforce, HD_Tata, HD_Western_Star, Heavy Truck Presentation Software
IRISBUS HD, IRIZAR HD, NEOPLAN HD, Peter HD, Renault HD, SETRA HD, Stannic Bavin, Sterling HD
Sunlong Bus, Sunwin Bus, UD Trucks 2F Nissan Diesel, WABCO ABS, Yang Chai Engine
Hardware Specifications
X-431 PAD V |
|
Operation System |
Android 7.1 (open system) |
CPU |
2.0GHz Octa-core |
Display |
10.1" Touch screen 1920*1200 |
Memory |
4GB |
Storage |
128GB |
Camera |
Rear 13MP, Front 8MP |
WiFi |
2.4GHz/5GHz dual WiFi |
Diagnostic Communication |
WiFi |
Working Temperature |
0℃~50℃ |
Dimension |
320*211*46 mm |
Smart Box 3.0 |
|
Processor and system |
Dual processor: Cortex – A7 + Cortex – M7 - Linux |
Memory |
256M |
Storage |
8GB |
Communication |
USB - Type B USB 2.0, Wifi Support 2.4G/5GHZ dual-band and Bluetooth - BLE 4.0 + EDR |
Working Voltage |
DC 9 ~36V |
Vehicle connection |
J1962 16PIN |
Optional Extension Modules:
-
Videoscope VSP600
Check hard-to-reach parts and get a direct image of the engine, cylinders, gears, compressors, heaters and valves, and body components. - X-431 PROG3
Add, delete, and reprogram keys; rewrite smart keys; replace key ECU. - TSGUN
Active and relearn TPMS sensors; and program LAUNCH TPMS sensor. - WiFi Printer
Print diagnostic data or reports for further analyzing and reviewing. - BST360
Check the SOH of the onboard battery, functionality of discharge capacity and start-up capacity, etc. Provide a reliable analysis basis for the inspection and maintenance of car batteries. - X-431 ADAS Mobile/PRO
Operate ADAS calibration to vehicle cameras, LKA system, ACC system, LDW system, and AVM system.
There is no additional software cost. The ADAS calibration software is already embedded in the PAD V. Only hardware needs to be purchased.
Launch X431 Pad V Package List:
- 1x X-431 PAD V main unit
- 1x X-431 PAD V charging dock
- 1x Smartbox 3.0 Diagnostic connector
- 1x Micro USB cable
- 1x Cigarette lighter cable
- 1x 5v DV out power adapter
- 1x Battery clamps cable
- 1x OBDII extension cable
- 1x Non-16pin connector converting cable
- 1x Password envelope
- 1x Non-16pin connectors set
If you have any questions please feel free to contact us, we are professional technicians with second to none expertise.
